SuperTrak VERTICAL10™ Design Starter Package

Start designing your system with SuperTrak VERTICAL10™ to discover the benefits of Smart Conveyance.

The Design Package is a great resource to start to understand how to create an effective system design using the SuperTrak VERTICAL10™ platform.

The Design Package includes:

SuperTrak VERTICAL10™ CAD

Design considerations document

System configuration options

Reference designs for tooling plates, shuttle shelves and frame extensions

Understanding specifications for applied forces/moments on the shuttle
